10μH - 22mH Surface Mount Power Inductors PCB Mounting Hole Bobbin Type 1415517C

Brand Name : Shareway

Model Number : 1415517C

Certification : RoHS,ISO9001-2001

Place of Origin : Guangdong,shenzhen

MOQ : 500/1000

Price : Supportive

Payment Terms : TT,Paypal,West Union

Supply Ability : 1kk-pcs/month

Delivery Time : Stock Or 3 weeks

Packaging Details : Reel/Tray

Product name : 10μH to 22mH PCB mounting hole Bobbin Type Inductors 1415517C

Inductance : 10μH to 22mH

Mounting : PCB mounting hole

Type : Bobbin Type Inductors

Application : PCB

Sample : Free samples

Contact Now

10μH to 22mH PCB mounting hole Bobbin Type Inductors 1415517C

Description:

Inductance,
(1kHz, 0.1VAC)

DC

Current

DC

Resistance

 Q at f kHz Q at f kHz SRF Mechanical Dimensions Mechanical Dimensions Mechanical Dimensions Mechanical Dimensions Mechanical Dimensions Footprint Footprint
±10% Max. Max. Nom. Nom. Nom. a b c d Øe f Øg
Part No. μH A Ω Q f MHz mm mm mm mm mm mm mm
1415517C 1.5mH 1.7 0.374 28 50 0.7 31.3 29.8 14.0 0.75 5.1 23.1 1.5
1422509C 2.2mH 0.9 1.000 43 50 0.9 25.3 24.4 18.5 0.48 5.5 23.2 0.9
1422512C 2.2mH 1.2 0.700 33 50 0.7 25.6 24.4 21.8 0.60 5.5 28.7 1.2
1422514C 2.2mH 1.4 0.622 33 50 0.6 31.1 29.8 14.0 0.67 5.1 23.0 1.3
1433507C 3.3mH 0.7 1.428 45 50 0.8 25.2 24.4 18.5 0.43 5.5 23.1 0.8
1433510C 3.3mH 1.0 1.992 20 50 0.7 25.5 24.4 21.8 0.54 5.5 28.6 1.0
1433512C 3.3mH 1.2 0.930 20 50 0.5 31.0 29.8 14.0 0.60 5.1 23.0 1.2
1447506C 4.7mH 0.6 2.200 60 50 0.6 25.2 24.4 18.5 0.39 5.5 23.1 0.7
1447508C 4.7mH 0.8 1.600 65 50 0.5 25.3 24.4 21.8 0.48 5.5 28.5 0.9
1447509C 4.7mH 0.9 1.400 57 10 0.5 30.9 29.8 14.0 0.54 5.1 23.0 1.0
1468505C 6.8mH 0.5 2.880 50 50 0.5 25.2 24.4 18.5 0.39 5.5 23.0 0.7
1468507C 6.8mH 0.7 2.300 47 50 0.4 25.2 24.4 21.8 0.43 5.5 28.5 0.8
1468508C 6.8mH 0.8 2.100 30 50 0.4 30.7 29.8 14.0 0.48 5.1 22.9 0.9
1410604C 10mH 0.4 4.340 51 50 0.4 25.1 24.4 18.5 0.34 5.5 23.0 0.6
1410605C 10mH 0.5 3.600 48 50 0.3 25.2 24.4 21.8 0.39 5.5 28.5 0.7
1410606C 10mH 0.6 2.600 48 50 0.2 30.9 29.8 21.8 0.54 5.1 28.3 1.0
1415604C 15mH 0.4 5.500 61 10 0.2 25.1 24.4 18.5 0.34 5.5 22.9 0.6
1415605C 15mH 0.5 3.740 55 10 0.2 30.6 29.8 21.8 0.43 5.1 28.4 0.8
1422604C 22mH 0.4 6.962 30 50 0.2 30.5 29.8 21.8 0.34 5.1 28.3 0.6

Dimensions:

10μH - 22mH Surface Mount Power Inductors PCB Mounting Hole Bobbin Type 1415517C
