Choke Coil SMD Power Inductor 1.5mm Height MHA0515NSGR33M With RoHS Approval

Brand Name : Shareway

Model Number : MHA0515NSGR33M

Certification : RoHS

Place of Origin : Guangdong,shenzhen

MOQ : 500/1000

Price : Supportive

Payment Terms : TT,Paypal,West Union

Supply Ability : 1kk-pcs/month

Delivery Time : Stock Or 3 weeks

Packaging Details : Reel/Tray

Product name : MHA0515NSGR33M SMD Power Inductor Choke Coil Inductor With RoHS

Height : 1.5mm

Inductance range : 0.33uH to 15.0uH

Type : SMD

Inductor : Choke Coil Inductor

Contact Now

MHA0515NSGR33M SMD Power Inductor Choke Coil Inductor With RoHS

Description:

Part number

Inductance

(uH±20%)

DCR(mΩ)@25℃

TYP.

DCR(mΩ)@25℃

MAX.

Irms

(A)

Isat

(A)
MHA0515NSGR33M 0.33 8.00 9.00 10.00 15.00
MHA0515NSG1R0M 1.00 20.00 23.00 6.50 9.00
MHA0515NSG1R2M 1.20 29.30 33.70 5.30 8.00
MHA0515NSG2R2M 2.20 58.00 64.00 3.30 6.00
MHA0515NSG3R3M 3.30 65.00 72.00 3.20 5.00
MHA0515NSG4R7M 4.70 95.00 106.0 3.00 4.00
MHA0515NSG6R8M 6.80 120.0 130.0 2.50 3.20
MHA0515NSG100M 10.0 153.0 170.0 2.00 3.00
MHA0515NSG150M 15.0 310.0 350.0 1.00 2.30

Dimensions:

Choke Coil SMD Power Inductor 1.5mm Height MHA0515NSGR33M With RoHS Approval
